Voltage range: AC100-240V / 50-60 Hz
Whole machine rated power: 850W
Light source: 19 pieces × 40W RGBW LED high-brightness imported light emitting diodes
Average life: 50,000h
Control mode: DMX512, RDM, master-slave mode
Channel mode: Built-in 7 channel mode 21 CH/ 23 CH/ 35 CH/ 78 CH/ 92 CH/ 97 CH/ 99CH
Scanning system: X stroke: 540° Y stroke: 216°
Optical system: High precision integrated structure lens, high transmittance quartz glass rod + PMMA lens
Optical angle: adjustable angle from 7° to 45°
Beam: The effect of the small angle beam is prominent.
Wash dyeing: even light distribution at medium angle
Color: RGBW color mixing system, uniform color mixing without flicker, fast color rainbow effect
Adjustable color temperature: 2500~10000 K
Effect macros: static effect macros and dynamic effect macros
Frequency: 1-25Hz electronic flashing and random multi-frequency flashing
Lighting: Electronic dimming, 4 dimming modes
Zoom system: Linear electric zoom
Lens rotation: 360° rotation of optical lens, variable kaleidoscope, small waist effect, etc.
Front halo light strip: can be controlled single point, freely chase flowing running color changing effect
Single circle control: The light source supports independent color change control of the inner and outer circles.
Single point control: The light source supports single independent control and color change.
Display screen: 1.77-inch OLED screen, Chinese and English dual-language menu, anti-interference optical signal isolation system, waterproof smart touch key (screen password 1111)
Intelligent control: Through the lamp menu, you can check the device usage and lighting time, device temperature, etc.
Channel data, software version information, etc.
Temperature control: intelligent temperature control, can automatically adjust the speed of the heat dissipation fan and overheat protection
Software upgrade: Upload upgrade file via DMX interface
Magnetic encoding positioning: non-contact magnetic rotary encoder positioning, signal feedback, absolute position memory
Casing material: latest second-generation structural waterproof design, metal die-casting aluminum casing and fire-resistant engineering plastic
Protection level: IP65, waterproof, dustproof, oil-proof design, suitable for all-weather use outdoors all year round
Lamp body size: 390 × 240 × 490mm
Carton size: 540 * 380 * 660mm
Net weight: 22kg Gross weight: 26kg
