Technical Parameters
Input voltage: AC110V-240V, 50-60Hz.
Total power: 650W.
Light source: 500W LED module lamp bead.
Light source life expectancy: about 50,000 hours.
Color temperature: 7800K.
Color wheel 1: 8 colors + white light, bidirectional rotating rainbow effect.
Color wheel 2: 3 colors + CTO linear adjustment (2800K-7800K).
Rotating gobo wheel: 7 rotating gobos + white light.
Zoom range: 4°- 40°, linear smooth zoom and focus.
Framing: controllable framing system with 4 blades, any spot can be created through the precise control of the blades.
Control channel: standard 26CH.
Control signal: Art-NET, RDM, DMX512, sound control, auto, master-slave.
System: Upgrade software for RDM control box.
Heat dissipation: lamp bead copper tube heat dissipation, axial flow type fan in and out of two-way heat dissipation cooling.
Display interface: 2.8-inch resistive color touch screen, with physical buttons, good pressing sensitivity.
Features:
1. high-temperature-resistant and flame-retardant engineering plastics and alloy materials.
2. Intelligent RDM mainboard remote device management, saving time and labor.
3. Magnetic levitation intelligent controllable-speed fan, better heat dissipation, and quieter.
4. Intelligent control temperature and speed.
5. Intelligent inverted display, always detect the fixture situation.
6. The color temperature in different places does not shake.
Product dimensions: L370 * W280 * H660mm.
Net weight: 22kg.
Carton packing dimensions: L770 * W380 * H490mm.
Gross weight: 25.5kg.
Flight case packing dimensions: 53 * 48 * 75cm.
Gross weight: 45kg.
Flight case packing dimensions: L900 * W440 * 860mm.(2PCS)
Gross weight: 70kg.(2PCS)
